Specs
- MODEL
- A2300N2-UTR_4
- FUEL SYSTEM
- WATER-COOLED DIESEL
- DISPLACEMENT, IN
- 139.5
- NUMBER OF CYLINDERS
- 4
- FUEL TANK SIZE, GAL
- 11.8
- RATED ENGINE POWER, HP
- 48
- RATED SPEED, RPM
- 2600
- MAX PTO POWER, HP
- 38.4
- DPF / SCR / DOC
- DPF / DOC
- TYPE
- 5045S/CS – SYNCHRO | 5045H/CH – HST
- NUMBER OF GEARS
- 5045S/CS – 16F / 16R | 5045H/CH – 4 RANGE
- MAXIMUM TOTAL FLOW, GPM
- 5045S/CS – 16.4 | 5045H/CH – 15.7
- IMPLEMENT PUMP CAP, GPM
- 5045S/CS – 11.4 | 5045H/CH – 10.7
- STEERING PUMP CAP, GPM
- 5
- 3P CATEGORY
- 1
- HITCH LIFT CAPACITY, LB
- 3,306
- AT 24 INCHES BEHIND LINK ENDS, LB
- 2,425
- OVERALL LENGTH, IN, 3P
- 127.4
- OVERALL WIDTH, IN
- 64.9
- HEIGHT TO TOP OF ROPS, IN
- 5045S/H – 98.4 | 5045CS/CH – 97
- WHEELBASE, IN
- 71.1
- MIN. GROUND CLEARANCE, IN
- 15.5
- WEIGHT, LB
- 5045S/H – 3,831 | 5045CS/CH – 4,349
- 540, 540E
- 584, 791
- Standard Bucket Size (in.)
- 72
- Maximum Lift Height (in.)
- 106.6
- Dig Depth (in.)
- 3.1
- Lift Capacity To Full Height At Pivot Pin (lbs.)
- 2,700
- Breakout Force (lbs.)
- 3,660
- Shipping Weight (lbs.)
- 1,075
- Standard Bucket Size (in.)
- 16
- Maximum Dig Depth (in.)
- 91.2
- Shipping Weight (lbs.)
- 1,500
