Bob Cat L35 Small Articulated Loader

The Bobcat® L35 small articulated loader combines agility with added power to tackle heavier lifting, loading and attachment work – all while keeping a light footprint. With higher rated operating capacity, powerful hydraulics and enhanced comfort features, the L35 is engineered to handle demanding jobs with confidence.

$69,670 USD**

As low as 0% for 36 months* or rebates up to $1,500 USD* / $2,000 CAD* in lieu of financing. Offers end December 31, 2025.

REQUEST QUOTE
GET FINANCING

L35 Key Specifications

L35
Horsepower
57 hp
Rated Operating Capacity (ISO) (Straight)
2072 lbs
Rated Operating Capacity (ISO) (Articulated)
1695 lbs
Operating Weight
6012 lbs
Lift Breakout Force (ISO)
4000 lbf
Auxiliary Std Flow
18 gpm
Width (over tires)
52.4 in
Ride Control
Optional
L35
Horsepower
57 hp
L35
Rated Operating Capacity (ISO) (Straight)
2072 lbs
Rated Operating Capacity (ISO) (Articulated)
1695 lbs
ROC with Counterweight Option – Articulated
2017 lbs
ROC with Counterweight Option – Straight
2472 lbs
Operating Weight
6012 lbs
Travel Speed
16.2 mph
Lift Breakout Force (ISO)
4000 lbf
L35
Fuel Tank
13.5 gal
L35
System Relief @ Quick Couplers
3045 psi
Auxiliary Std Flow
18 gpm
Auxiliary High Flow
25.3 gpm
L35
Height to Bucket Hinge Pin – Extended
114.8 in
Height to Bucket Hinge Pin – Retracted
88.2 in
Inside Turning Radius
92.8 in
Outside Turning Radius
111.2 in
Length
148.5 in
Articulation Angle
43 deg
Length without Attachment
110.9 in
Length with Standard Bucket
148.5 in
Width (with bucket)
54 in
Width (over tires)
52.4 in
Height with Operator Cab
82.2 in
Dump Angle @ Maximum Height
40 deg
Reach @ Maximum Height
38.6 in
Ground Clearance
6.5 in
Rollback Angle
32 deg
Wheelbase
57.2 in
Tire Size
26X12-12 10 PLY
Wheel Tread
40.3 in
L35
Auxiliary Hydraulics Type
Finger Tip Control
L35
Main Drive
Hydrostatic pump driving 4 independent wheel motors
L35
L35
L35
Front and Rear Work Lights
Standard
Air Conditioning
Optional
Adjustable Seat
Standard
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Enclosure
Optional
ROPS/FOPS Approved
Standard
Cab Heater
Optional
Operating Lights
Standard
Auto Idle
Optional
Traction Control
Optional
Radio
Optional
Turbocharged Engine
Standard
Rear Window
Optional
Rotating Flashing Beacon
Optional
Lift-Arm Support
Standard
Grab Handles
N/A
Seat Belt
Standard
Suspension Seat
Standard
Turn Signals
Optional
Two Speed Travel
Standard
Deluxe Instrumentation
Not Applicable
Hydraulic Bucket Positioning
Standard
High Flow Option
Optional
Auxiliary Hydraulics
Standard
Spark Arrestor Muffler
Standard
Bob-Tach Attachment System
Standard
Tires-Ply Rating
10
Heavy-Duty Float Tires
Optional
Power Bob-Tach
Optional
Ride Control
Optional
Cup Holder
Standard
Horn
Standard
L35
