| Specifications | 8’2″ Steel DXT | 9’2″ Steel DXT | 8’2″ Stainless Steel DXT | 9’2″ Stainless Steel DXT | 8’2″ Poly DXT | 9’2″ Poly DXT | 10′ Steel DXT |
|---|---|---|---|---|---|---|---|
| Attachment System | SmartHitch 2 | SmartHitch 2 | SmartHitch 2 | SmartHitch 2 | SmartHitch 2 | SmartHitch 2 | SmartHitch 2 |
| Base Angle | 0.5 in. x 6 in. (1.3 cm x 15 cm) | 0.5 in. x 6 in. (1.3 cm x 15 cm) | 0.5 in. x 6 in. (1.3 cm x 15 cm) | 0.5 in. x 6 in. (1.3 cm x 15 cm) | 0.5 in. x 6 in. (1.3 cm x 15 cm) | 0.5 in. x 6 in. (1.3 cm x 15 cm) | 0.5 in. x 6 in. (1.3 cm x 15 cm) |
| Blade Height | 30 in (76 cm) at center, 37.5 in (95 cm) at end | 30 in (76 cm) at center, 37.5 in (95 cm) at end | 30 in (76 cm) at center, 37.5 in (95 cm) at end | 30 in (76 cm) at center, 37.5 in (95 cm) at end | 30 in (76 cm) at center, 37.5 in (95 cm) at end | 30 in (76 cm) at center, 37.5 in (95 cm) at end | 35 in (88 cm) at center, 45 in (114 cm) at end |
| Blade Material | Steel | Steel | Stainless Steel | Stainless Steel | Poly | Poly | Steel |
| Blade Size | 8 ft. 2 in. | 9 ft. 2 in. | 8 ft. 2 in. | 9 ft. 2 in. | 8 ft. 2 in. | 9 ft. 2 in. | 10 ft. |
| Blade Thickness | 11-ga Steel | 11-ga Steel | 14-ga 304 Stainless | 14-ga 304 Stainless | 0.375 in. (0.95 cm) Poly | 0.375 in. (0.95 cm) Poly | 11-ga Steel |
| Blade Width (Scoop) | Curb Guard Width | 81 in (206 cm) | 92 in (234 cm) | 81 in (206 cm) | 92 in (234 cm) | 81 in (206 cm) | 92 in (234 cm) | 102 in (259 cm) |
| Blade Width (V-Position) | Curb Guard Width | 88 in (224 cm) | 99 in (251 cm) | 88 in (224 cm) | 99 in (251 cm) | 88 in (224 cm) | 99 in (251 cm) | 107 in (272 cm) |
| Blade Width | Curb Guard Width | 98 in. (249 cm) | 110 in. (279 cm) | 98 in. (249 cm) | 110 in. (279 cm) | 98 in. (249 cm) | 110 in. (279 cm) | 120 in. (305 cm) |
| D-Force | Optional | Optional | Optional | Optional | Optional | Optional | Not an Option |
| Lift Cylinder | 2″ x 1 1/8 ” x 10″ (5 cm x 3 cm x 25 cm) | 2″ x 1 1/8 ” x 10″ (5 cm x 3 cm x 25 cm) | 2″ x 1 1/8 ” x 10″ (5 cm x 3 cm x 25 cm) | 2″ x 1 1/8 ” x 10″ (5 cm x 3 cm x 25 cm) | 2″ x 1 1/8 ” x 10″ (5 cm x 3 cm x 25 cm) | 2″ x 1 1/8 ” x 10″ (5 cm x 3 cm x 25 cm) | 2 1/4″ x 1 1/8 ” x 12″ (6 cm x 3 cm x 31 cm) |
| Lighting | SL3 L.E.D. with Ice Shield Technology | SL3 L.E.D. with Ice Shield Technology | SL3 L.E.D. with Ice Shield Technology | SL3 L.E.D. with Ice Shield Technology | SL3 L.E.D. with Ice Shield Technology | SL3 L.E.D. with Ice Shield Technology | SL3 L.E.D. with Ice Shield Technology |
| Plow Shoes | Optional | Optional | Optional | Optional | Optional | Optional | Optional |
| Plow Type | V-Plow | V-Plow | V-Plow | V-Plow | V-Plow | V-Plow | V-Plow |
| Plowing Width at 30 degree Angle | 85″ (216 cm) | 95″ (241 cm) | 85″ (216 cm) | 95″ (241 cm) | 85″ (216 cm) | 95″ (241 cm) | 104″ (264 cm) |
| Reinforcement Ribs | 6 Vertical, 2 Diagonal | 8 Vertical, 2 Diagonal | 6 Vertical, 2 Diagonal | 8 Vertical, 2 Diagonal | 6 Vertical, 2 Diagonal | 8 Vertical, 2 Diagonal | 8 Vertical, 2 Diagonal |
| SmartLock Cylinders | 1 1/2″ x 10″ (4 cm x 25 cm) | 1 1/2″ x 10″ (4 cm x 25 cm) | 1 1/2″ x 10″ (4 cm x 25 cm) | 1 1/2″ x 10″ (4 cm x 25 cm) | 1 1/2″ x 10″ (4 cm x 25 cm) | 1 1/2″ x 10″ (4 cm x 25 cm) | 2″ x 10″ (5 cm x 25 cm) |
| Trip Mechanism | Dual-Trip | Dual-Trip | Dual-Trip | Dual-Trip | Dual-Trip | Dual-Trip | Dual-Trip |
| Trip Springs | 3 Torsion Springs (per blade half) | 3 Torsion Springs (per blade half) | 3 Torsion Springs (per blade half) | 3 Torsion Springs (per blade half) | 3 Torsion Springs (per blade half) | 3 Torsion Springs (per blade half) | 3 Torsion Springs (per blade half) |
| Trip Springs (Moldboard) | 4 Extension Springs | 4 Extension Springs | 4 Extension Springs | 4 Extension Springs | 4 Extension Springs | 4 Extension Springs | 4 Extension Springs |
| Truck Applications | 3/4 & 1 Ton | 3/4 & 1 Ton | 3/4 & 1 Ton | 3/4 & 1 Ton | 3/4 & 1 Ton | 3/4 & 1 Ton | Medium Duty |
| Vehicle | Truck | Truck | Truck | Truck | Truck | Truck | Truck |
| Weight | 868 lbs / 394 kg | 925 lbs / 420 kg | 920 lbs / 417 kg | 977 lbs / 433 kg | 878 lbs / 398 kg | 935 lbs / 424 kg | 1,205 lbs / 546.58 kg |
