Specifications | VBX+ 1.5 Yard Auger | VBX+ 1.5 Yard Pintle | VBX+ 2 Yard Auger | VBX+ 2 Yard Pintle | VBX+ 3 Yard Auger | VBX+ 3 Yard Pintle |
---|---|---|---|---|---|---|
Capacity | cubic yd 1.5 / cubic m 1.15 | cubic yd 1.5 / cubic m 1.15 | cubic yd 2 / cubic m 1.53 | cubic yd 2 / cubic m 1.53 | cubic yd 3 / cubic m 2.3 | cubic yd 3 / cubic m 2.3 |
Chute Construction | Polyethylene with Stainless Steel Frame | Polyethylene with Stainless Steel Frame | Polyethylene with Stainless Steel Frame | Polyethylene with Stainless Steel Frame | Polyethylene with Stainless Steel Frame | Polyethylene with Stainless Steel Frame |
Connectivity | Smart Compatible | Smart Compatible | Smart Compatible | Smart Compatible | Smart Compatible | Smart Compatible |
Control | Dual Variable Speed Control | Dual Variable Speed Control | Dual Variable Speed Control | Dual Variable Speed Control | Dual Variable Speed Control | Dual Variable Speed Control |
Deflector | Standard | Standard | Standard | Standard | Standard | Standard |
Display Type | LCD Display Controller | LCD Display Controller | LCD Display Controller | LCD Display Controller | LCD Display Controller | LCD Display Controller |
Feed Mechanism | Auger | Pintle/Conveyor Chain | Auger | Pintle/Conveyor Chain | Auger | Pintle/Conveyor Chain |
Feed Motor | 3/4 HP Feed Motor | 3/4 HP Feed Motor | 3/4 HP Feed Motor | 3/4 HP Feed Motor | 3/4 HP Feed Motor | 3/4 HP Feed Motor |
Gearbox | Planetary Worm 91:1 | Planetary Worm 137:1 | Planetary Worm 91:1 | Planetary Worm 137:1 | Planetary Worm 91:1 | Planetary Worm 137:1 |
Grease Hoses | Standard | Standard | Standard | Standard | Standard | Standard |
Hopper Construction | 3/16″ (0.5 cm) Double Wall Polyethylene Hopper | 3/16″ (0.5 cm) Double Wall Polyethylene Hopper | 3/16″ (0.5 cm) Double Wall Polyethylene Hopper | 3/16″ (0.5 cm) Double Wall Polyethylene Hopper | 3/16″ (0.5 cm) Double Wall Polyethylene Hopper | 3/16″ (0.5 cm) Double Wall Polyethylene Hopper |
Hopper Cover | VCP Tarp w/ integral tie-downs | VCP Tarp w/ integral tie-downs | VCP Tarp w/ integral tie-downs | VCP Tarp w/ integral tie-downs | VCP Tarp w/ integral tie-downs | VCP Tarp w/ integral tie-downs |
Hopper Height | 38 in / 96.52 cm | 38 in / 96.52 cm | 38 in / 96.52 cm | 38 in / 96.52 cm | 49 in / 124.46 cm | 49 in / 124.46 cm |
Hopper Length | 78 in / 198 cm | 78 in / 198 cm | 96 in / 244 cm | 96 in / 244 cm | 108 in / 274 cm | 108 in / 274 cm |
Hopper Width | 48.25 in / 122.56 cm | 48.25 in / 122.56 cm | 48.25 in / 122.56 cm | 48.25 in / 122.56 cm | 48 in / 121.92 cm | 48 in / 121.92 cm |
Inverted V-Baffle | Standard | Optional | Standard | Optional | Standard | Optional |
LED CHSML | Standard | Standard | Standard | Standard | Standard | Standard |
LED Strobe Lights | Standard (Two) | Standard (Two) | Standard (Two) | Standard (Two) | Standard (Two) | Standard (Two) |
LED Work Lights | Standard (Two) | Standard (Two) | Standard (Two) | Standard (Two) | Standard (Two) | Standard (Two) |
Material Conveying Method | 6″ (15 cm) OD x 9″ (23 cm) Pitch Full Length Auger | 14″ (36 cm) Wide Pintle Chain | 6″ (15 cm) OD x 9″ (23 cm) Pitch Full Length Auger | 14″ (36 cm) Wide Pintle Chain | 6″ (15 cm) OD x 9″ (23 cm) Pitch Full Length Auger | 14″ (36 cm) Wide Pintle Chain |
Max Feed Rate | 150 lbs (70 kg) per minute | 240 lbs (110 kg) per minute | 150 lbs (70 kg) per minute | 240 lbs (110 kg) per minute | 150 lbs (70 kg) per minute | 240 lbs (110 kg) per minute |
Minimum Bed Length | 66 in (168 cm) | 66 in (168 cm) | 78 in (198 cm) | 78 in (198 cm) | 96 in (243.8 cm) | 96 in (243.8 cm) |
Spinner | 15 in (38.1 cm) Diameter Poly Spinner | 15 in (38.1 cm) Diameter Poly Spinner | 15 in (38.1 cm) Diameter Poly Spinner | 15 in (38.1 cm) Diameter Poly Spinner | 15 in (38.1 cm) Diameter Poly Spinner | 15 in (38.1 cm) Diameter Poly Spinner |
Spinner Assembly | Easily Removable/Swing Out and Height Adjustable | Easily Removable/Swing Out and Height Adjustable | Easily Removable/Swing Out and Height Adjustable | Easily Removable/Swing Out and Height Adjustable | Easily Removable/Swing Out and Height Adjustable | Easily Removable/Swing Out and Height Adjustable |
Spinner Gearmotor | 1/2 HP Spinner Gearmotor (Located above spinner) | 1/2 HP Spinner Gearmotor (Located above spinner) | 1/2 HP Spinner Gearmotor (Located above spinner) | 1/2 HP Spinner Gearmotor (Located above spinner) | 1/2 HP Spinner Gearmotor (Located above spinner) | 1/2 HP Spinner Gearmotor (Located above spinner) |
Spreader Overall Length | 93.5 in / 237 cm | 93.5 in / 237 cm | 115 in / 292 cm | 115 in / 292 cm | 122 in / 309 cm | 122 in / 309 cm |
Spreader Switches | Two Dual Function Rocker Switches, E-Stop | Two Dual Function Rocker Switches, E-Stop | Two Dual Function Rocker Switches, E-Stop | Two Dual Function Rocker Switches, E-Stop | Two Dual Function Rocker Switches, E-Stop | Two Dual Function Rocker Switches, E-Stop |
Spreading Width | 8 ft – 40 ft (2.4 m – 12 m) Dry free-flowing material | 8 ft – 40 ft (2.4 m – 12 m) Dry free-flowing material | 8 ft – 40 ft (2.4 m – 12 m) Dry free-flowing material | 8 ft – 40 ft (2.4 m – 12 m) Dry free-flowing material | 8 ft – 40 ft (2.4 m – 12 m) Dry free-flowing material | 8 ft – 40 ft (2.4 m – 12 m) Dry free-flowing material |
Tie-Down Kit | Standard | Standard | Standard | Standard | Standard | Standard |
Top Screen | Standard | Standard | Standard | Standard | Standard | Standard |
Trough | 11 ga. Stainless Steel | 11 ga. Stainless Steel | 11 ga. Stainless Steel | 11 ga. Stainless Steel | 11 ga. Stainless Steel | 11 ga. Stainless Steel |
Vehicle Application | 3/4 T & 1 T | 3/4 T & 1 T | 3/4 T & 1 T | 3/4 T & 1 T | 15,000+ GVWR | 15,000+ GVWR |
Vehicle to Spreader Connector | Custom Sealed and Overmolded Power & Controls Connector | Custom Sealed and Overmolded Power & Controls Connector | Custom Sealed and Overmolded Power & Controls Connector | Custom Sealed and Overmolded Power & Controls Connector | Custom Sealed and Overmolded Power & Controls Connector | Custom Sealed and Overmolded Power & Controls Connector |
Vibrator | Standard (Dual Vibrator) | Optional | Standard (Dual Vibrator) | Optional | Standard (Dual Vibrator) | Optional |
Weight | 640 lbs / 290 kg | 680 lbs / 308 kg | 690 lbs / 313 kg | 730 lbs / 331 kg | 810 lbs / 367 kg | 840 lbs / 381 kg |
