Specs
|
T25 + Grass255-4t, US49, CA SKU: 970 73 25‑03 |
|
|---|---|
| Engine |
T25 + Grass255-4t, US49, CA
SKU: 970 73 25‑03
|
Cylinder displacement |
1.32 cu.inch |
Output shaft power1 |
0.8 hp |
Fuel tank volume |
10.14 fl oz (US) |
Fuel consumption |
630 g/kWh |
Maximum power speed |
7,800 rpm |
Idling speed |
2,800 rpm |
Maximum rpm output shaft |
7,200 rpm |
Electrode gap |
0.02 in |
Clutch engagement speed (±120) |
4,200 rpm |
Torque, max. |
0.8 Nm |
Torque, max. at rpm |
6,000 rpm |
Spark Plug |
Husqvarna HQT-4 672201 |
Output shaft thread |
M10x1.25V |
| Equipment | |
Grass blade |
Grass 255-4 |
Harness |
Single harness |
Saw blade |
Not included |
Trimmer head |
T25 (L) |
Handle type |
Loop |
| Control | |
Connectivity |
Not applicable |
| Capacity | |
Cutting width |
17 in |
| Transmission | |
Gear ratio |
0.68 |
Drive gear angle |
30 ° |
| Dimensions | |
Tube diameter |
1 in |
Weight (excl. cutting equipment) |
10.14 lbs |
Tube length |
57.677 in |
| Lubricant | |
Lubricant type (Engine) |
Husqvarna 2 stroke or equiv. at 50:1 |
Lubricant type (bevel gear) |
Mineral grease |
| Sound and noise | |
Sound pressure level at operators ear |
90 dB(A) |
Sound power level, guaranteed (LWA) |
0 dB(A) |
Sound power level, measured |
97.8 dB(A) |
| Emission | |
Exhaust emissions (HC average) EU |
42.02 g/kWh |
Exhaust emissions (HC average) CARB |
31.56 g/kWh |
Exhaust emissions (HC average) EPA |
42.02 g/kWh |
Exhaust emissions (CO average) EU |
230.89 g/kWh |
Exhaust emissions (CO average) EPA |
254.87 g/kWh |
Exhaust emissions (CO average) CARB |
30.3 g/kWh |
Exhaust emissions (NOx average) EU |
2.98 g/kWh |
Exhaust emissions (NOx average) EPA |
2.98 g/kWh |
Exhaust emissions (NOx average) CARB |
1.82 g/kWh |
| Vibration | |
Equivalent vibration level (ahv, eq) left handle |
0 m/s² |
Equivalent vibration level (ahv, eq) right handle |
0 m/s² |
