$399.99
|
18″ .325″, 1,3 mm, H30, SN,FA saw RTLBx
970 61 23‑38
|
|---|
|
18″ .325″, 1,3 mm, H30, SN,FA saw RTLBx
970 61 23‑38
|
|
|---|---|
|
Engine
|
|
Output shaft power1 |
2.4 hp
|
Cylinder displacement |
40.9 cm³
|
Torque, max. |
2.16 Nm
|
Torque, max. at rpm |
6,300 rpm
|
Chain speed at max power |
56.76 fts
|
Clutch engagement speed (±120) |
4,300 rpm
|
Electrode gap |
0.02 in
|
Idling speed |
2,900 rpm
|
Ignition module air gap |
0.01 in
|
Maximum power speed |
9,000 rpm
|
Oil pump type |
Fixed flow
|
Spark Plug |
Champion RCJ7Y, NGK BPMR7A
|
|
18″ .325″, 1,3 mm, H30, SN,FA saw RTLBx
970 61 23‑38
|
|
|---|---|
|
Equipment
|
|
Recommended bar length, min |
13 in
|
Pitch |
.325″
|
Recommended bar length, max |
18 in
|
Chain type |
H30
|
Bar length |
45 cm
|
Bar length (inch) |
18 in
|
Sprocket type |
Spur 7
|
Gauge |
.050″
|
|
18″ .325″, 1,3 mm, H30, SN,FA saw RTLBx
970 61 23‑38
|
|
|---|---|
|
Dimensions
|
|
Weight (excl. cutting equipment) |
9.78 lbs
|
|
18″ .325″, 1,3 mm, H30, SN,FA saw RTLBx
970 61 23‑38
|
|
|---|---|
|
Sound and noise
|
|
Sound pressure level at operators ear (LpA) |
102 dB(A)
|
Sound power level, guaranteed (LWA) |
114 dB(A)
|
Sound power level, measured |
112 dB(A)
|
|
18″ .325″, 1,3 mm, H30, SN,FA saw RTLBx
970 61 23‑38
|
|
|---|---|
|
Vibration
|
|
Equivalent vibration level (ahv, eq) rear handle |
4.2 m/s²
|
Equivalent vibration level (ahv, eq) front handle |
3.8 m/s²
|
|
18″ .325″, 1,3 mm, H30, SN,FA saw RTLBx
970 61 23‑38
|
|
|---|---|
|
Lubricant
|
|
Oil tank volume |
0.53 US pint
|
Lubricant type (Engine) |
Husqvarna 2 stroke or equiv. at 50:1
|
|
18″ .325″, 1,3 mm, H30, SN,FA saw RTLBx
970 61 23‑38
|
|
|---|---|
|
Emission
|
|
Exhaust emissions (CO₂ EU V)2 |
813 g/kWh
|
