$469.99
|
12″ SN 3/8 mini” 1,3 mm H37
966 99 72‑03
|
12″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑32
|
14″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑34
|
16″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑36
|
|
|---|---|---|---|---|
|
Engine
|
||||
Output shaft power1 |
2.01 hp
|
2.01 hp
|
2.01 hp
|
2.01 hp
|
Cylinder displacement |
35.2 cm³
|
35.2 cm³
|
35.2 cm³
|
35.2 cm³
|
Torque, max. |
1.57 Nm
|
1.57 Nm
|
1.57 Nm
|
1.57 Nm
|
Torque, max. at rpm |
7,500 rpm
|
7,500 rpm
|
7,500 rpm
|
7,500 rpm
|
Chain speed at max power |
62.3 fts
|
62.3 fts
|
62.3 fts
|
62.3 fts
|
Clutch engagement speed (±120) |
4,700 rpm
|
4,700 rpm
|
4,700 rpm
|
4,700 rpm
|
Electrode gap |
0.03 in
|
0.03 in
|
0.03 in
|
0.03 in
|
Idling speed |
2,900 rpm
|
2,900 rpm
|
2,900 rpm
|
2,900 rpm
|
Ignition module air gap |
0.02 in
|
0.02 in
|
0.02 in
|
0.02 in
|
Maximum power speed |
10,000 rpm
|
10,000 rpm
|
10,000 rpm
|
10,000 rpm
|
Oil pump capacity, max |
9 ml/min
|
9 ml/min
|
9 ml/min
|
9 ml/min
|
Oil pump capacity, min |
3 ml/min
|
3 ml/min
|
3 ml/min
|
3 ml/min
|
Oil pump type |
Automatic
|
Automatic
|
Automatic
|
Automatic
|
Spark Plug |
NGK CMR6H
|
NGK CMR6H
|
NGK CMR6H
|
NGK CMR6H
|
|
12″ SN 3/8 mini” 1,3 mm H37
966 99 72‑03
|
12″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑32
|
14″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑34
|
16″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑36
|
|
|---|---|---|---|---|
|
Equipment
|
||||
Recommended bar length, min |
12 in
|
12 in
|
12 in
|
12 in
|
Pitch |
3/8″ mini
|
3/8″ mini
|
3/8″ mini
|
3/8″ mini
|
Recommended bar length, max |
14 in
|
14 in
|
14 in
|
14 in
|
Chain type |
–
|
H37
|
H37
|
H37
|
Bar length |
30 cm
|
30 cm
|
35 cm
|
40 cm
|
Bar length (inch) |
12 in
|
12 in
|
14 in
|
16 in
|
Sprocket type |
Spur 6
|
Spur 6
|
Spur 6
|
Spur 6
|
Gauge |
.050″
|
.050″
|
.050″
|
.050″
|
|
12″ SN 3/8 mini” 1,3 mm H37
966 99 72‑03
|
12″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑32
|
14″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑34
|
16″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑36
|
|
|---|---|---|---|---|
|
Dimensions
|
||||
Weight (excl. cutting equipment) |
7.5 lbs
|
7.5 lbs
|
7.5 lbs
|
7.5 lbs
|
|
12″ SN 3/8 mini” 1,3 mm H37
966 99 72‑03
|
12″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑32
|
14″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑34
|
16″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑36
|
|
|---|---|---|---|---|
|
Sound and noise
|
||||
Sound pressure level at operators ear (LpA) |
103 dB(A)
|
103 dB(A)
|
103 dB(A)
|
103 dB(A)
|
Sound power level, guaranteed (LWA) |
114 dB(A)
|
114 dB(A)
|
114 dB(A)
|
114 dB(A)
|
Sound power level, measured |
112 dB(A)
|
112 dB(A)
|
112 dB(A)
|
112 dB(A)
|
|
12″ SN 3/8 mini” 1,3 mm H37
966 99 72‑03
|
12″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑32
|
14″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑34
|
16″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑36
|
|
|---|---|---|---|---|
|
Vibration
|
||||
Equivalent vibration level (ahv, eq) rear handle |
3.9 m/s²
|
3.9 m/s²
|
3.9 m/s²
|
3.9 m/s²
|
Equivalent vibration level (ahv, eq) front handle |
3.6 m/s²
|
3.6 m/s²
|
3.6 m/s²
|
3.6 m/s²
|
|
12″ SN 3/8 mini” 1,3 mm H37
966 99 72‑03
|
12″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑32
|
14″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑34
|
16″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑36
|
|
|---|---|---|---|---|
|
Lubricant
|
||||
Oil tank volume |
0.36 US pint
|
0.36 US pint
|
0.36 US pint
|
0.36 US pint
|
Lubricant type (Engine) |
Husqvarna 2 stroke or equiv. at 50:1
|
Husqvarna 2 stroke or equiv. at 50:1
|
Husqvarna 2 stroke or equiv. at 50:1
|
Husqvarna 2 stroke or equiv. at 50:1
|
|
12″ SN 3/8 mini” 1,3 mm H37
966 99 72‑03
|
12″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑32
|
14″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑34
|
16″ Bar, .3/8″ Pitch, .050″ Gauge
966 99 72‑36
|
|
|---|---|---|---|---|
|
Emission
|
||||
Exhaust emissions (CO₂ EU V)2 |
860 g/kWh
|
860 g/kWh
|
860 g/kWh
|
860 g/kWh
|
