Specs
| VSS-2000 | VSS-3000 |
|---|
| Vehicle Compatibility | ¾- or 1-Ton Pickup Truck | ¾- or 1-Ton Pickup Truck |
| Vehicle Compatibility | ¾- or 1-Ton Pickup Truck | ¾- or 1-Ton Pickup Truck |
| Approx. Weight (Empty) | 450 lb | 520 lb |
| Approx. Weight (Empty) | 204.1 kg | 235.9 kg |
| Overall Dimensions (LxWxH) | 88″ x 82″ boom x 64″ | 94″ x 82″ boom x 68″ |
| Overall Dimensions (LxWxH) | 223.5 cm x 208.3 cm boom x 162.6 cm | 238.8 cm x 208.3 cm boom x 172.7 cm |
| Floor Length | 74″ | 80″ |
| Floor Length | 188.0 cm | 203.2 cm |
| Floor Width | 36″ | 39″ |
| Floor Width | 91.4 cm | 99.1 cm |
| Tank Dimensions (LxW) | 47″ x 37″ | 60″ x 42″ |
| Tank Length | 119.4 cm x 94.0 cm | 152.4 cm x 106.7 cm |
| Capacity | 200 gal | 300 gal |
| Capacity | 757.1 L | 1,135.6 L |
| Spraying Width | Up to 25′ | Up to 25′ |
| Spraying Width | Up to 7.6 m | Up to 7.6 m |
| Spraying Volume | 20 gal per lane mile/acre at 10 mph | 20 gal per lane mile/acre at 10 mph |
| Spraying Volume | 75.7 L per lane mile/acre at 16.1 kph | 75.7 L per lane mile/acre at 16.1 kph |
| Wiring Harness | Completely loomed with molded plugs | Completely loomed with molded plugs |
| Wiring Harness | Completely loomed with molded plugs | Completely loomed with molded plugs |
| Motors | 12V direct-drive pumps | 12V direct-drive pumps |
| Motors | 12V direct-drive pumps | 12V direct-drive pumps |
| Mounting | Straps included | Straps included |
| Mounting | Straps included | Straps included |
