Specs
| 8.6 HDV | 9.6 HDV |
|---|
| Moldboard Options | Stainless or Powder-Coated Steel | Stainless or Powder-Coated Steel |
| Moldboard Options | Stainless or Powder-Coated Steel | Stainless or Powder-Coated Steel |
| Blade Type | V-Plow | V-Plow |
| Blade Type | V-Plow | V-Plow |
| Vehicle Compatibility | Truck Class 2 – 6 (under 26,000 lb GVWR) & Tractors | Truck Class 2 – 6 (under 26,000 lb GVWR) & Tractors |
| Vehicle Compatibility | Truck Class 2 – 6 (under 26,000 lb GVWR) & Tractors | Truck Class 2 – 6 (under 26,000 lb GVWR) & Tractors |
| Approx. Weight* | 950 lbs | 1,020 lbs |
| Approx. Weight* | 430 kg | 462 kg |
| Plowing Width (Straight) | Straight: 102″ – 112.5″ (w/ Wings) V: 92″ – 115″ (w/ Wings) Scoop: 86″ – 98″ (w/ Wings) |
Straight: 114″ – 124.5″ (w/ Wings) V: 103″ – 126″ (w/ Wings) Scoop: 98″ – 110″ (w/ Wings) |
| Plowing Width (Straight) | Straight: 259 cm – 285.8 cm (w/ Wings) V: 233.7 cm – 292.1 cm (w/ Wings) Scoop: 218.4 cm – 249 cm (w/ Wings) |
Straight: 289.5 cm – 316.2 cm (w/ Wings) V: 261.6 cm – 320 cm (w/ Wings) Scoop: 249 cm – 279.4 cm (w/ Wings) |
| Plowing Width (Full Angle) | 90″ -115″ w/ Wings | 103.2″ – 118″ w/ Wings |
| Plowing Width (Full Angle) | 228.6 cm – 292.1 cm w/ Wings | 262.1 cm – 299.7 cm w/ Wings |
| Blade Width | 8’6″ | 9’6″ |
| Blade Width | 259.1 cm | 289.6 cm |
| Blade Height | At Hinge: 31″ At End: 38″ |
At Hinge: 31″ At End: 39″ |
| Blade Height | At Hinge; 78.7 cm At End: 96.5 cm |
At Hinge: 78.7 cm At End: 99.1 cm |
| Angle Cylinders | 1.75″ x 11″ | 1.75″ x 11″ |
| Angle Cylinders | 4.4 cm x 27.9 cm | 4.4 cm x 27.9 cm |
| Cutting Edge | ⅜” (Standard) | ½” (Standard) |
| Cutting Edge | 0.953 cm (Standard) | 1.3 cm (Standard) |
| Blade Thickness | 16 ga | 16 ga |
| Blade Thickness | 16 ga | 16 ga |
| Reinforcement Ribs | 6 vertical/1 angle | 8 vertical/1 angle |
| Reinforcement Ribs | 6 vertical/1 angle | 8 vertical/1 angle |
| Trip Springs | 4 steel | 6 steel |
| Trip Springs | 4 steel | 6 steel |
