Specs
| 8100PP | 8611PP |
|---|
| Moldboard Options | Powder-Coated Steel | Powder-Coated Steel |
| Moldboard Options | Powder-Coated Steel | Powder-Coated Steel |
| Blade Type | Adjustable Winged Blade | Adjustable Winged Blade |
| Blade Type | Adjustable Winged Blade | Adjustable Winged Blade |
| Vehicle Compatibility | Class 2-5 Trucks & Tractors | Class 2-6 Trucks |
| Vehicle Compatibility | Class 2-5 Trucks & Tractors | Class 2-6 Trucks |
| Approx. Weight* | 970 lbs | 1,036 lbs |
| Approx. Weight* | 439 kg | 469 kg |
| Plowing Width (Straight) | 96″ – Compact 105″ – BUCKET BLADE™ 120″ – WIDE PASS |
102″ – Compact 118″ – BUCKET BLADE 132″ – WIDE PASS |
| Plowing Width (Straight) | 243.8 cm – Compact 266.7 cm – BUCKET BLADE 304.8 cm – WIDE PASS |
259.1 cm – Compact 299.7 cm – BUCKET BLADE 335.3 cm – WIDE PASS |
| Plowing Width (Full Angle) | 85.6″ – Compact 93.4″ – BUCKET BLADE 95.1″ – Windrow 106.2″ – WIDE PASS |
94.5″ – Compact 114.5″ – BUCKET BLADE 113″ – Windrow 126″ – WIDE PASS |
| Plowing Width (Full Angle) | 217.4 cm – Compact 237.2 cm- BUCKET BLADE 241.6 cm – Windrow 269.8 cm – WIDE PASS |
240 cm – Compact 290.8 cm – BUCKET BLADE 287 cm – Windrow 320 cm – WIDE PASS |
| Blade Width | 8′ – 10′ | 8′ 6″ – 11′ |
| Blade Width | 243.8 cm – 304.8 cm | 259.1 cm – 335.3 cm |
| Blade Height | 31″ | 31″ |
| Blade Height | 78.7 cm | 78.7 cm |
| Angle Cylinders | 1½” | 1½” |
| Angle Cylinders | 3.8 cm | 3.8 cm |
| Cutting Edge | Blade: ½” x 6″ Wing: ¼” x 10″ |
Blade: ½” x 6″ Wing: ¼” x 10″ |
| Cutting Edge | Blade: 1.3 cm x 15.2 cm Wing: 0.635 cm x 25.4 cm |
Blade: 1.3 cm x 15.2 cm Wing: 0.635 cm x 25.4 cm |
| Blade Thickness | Blade: 12 ga Wing: 11 ga |
Blade: 12 ga Wing: 11 ga |
| Blade Thickness | Blade: 12 ga Wing: 11 ga |
Blade: 12 ga Wing: 11 ga |
| Reinforcement Ribs | 4 | 4 |
| Reinforcement Ribs | 4 | 4 |
| Trip Springs | 4 steel | 6 steel |
| Trip Springs | 4 steel | 6 steel |
