| Air Filter |
Heavy-Duty Canister Air Cleaner Air Filtration System with Electronic Vacuum Sensor |
| Anti Scalp Wheels |
13 Standard |
| Armrests |
Standard |
| Blade Tip Speed |
18,100 ft/min / 5,516 m/min |
| Blades |
4 blades at 24.5 in. length |
| Box Dimensions |
97.3 in. x 75.7 in. x 72 in. / 247.1 cm x 192.3 cm x 182.9 cm |
| CARB Compliant |
CARB Compliant |
| Caster Tires |
15 in. x 6 in. – 6 in. (38.1 cm x 15.2 cm x 15.2 cm) Flat-Free Semi-Pneumatic |
| Clutch |
Wet Disc |
| Deck Design |
7-Gauge TURBO FORCE® w/ Bull-Nose Bumper |
| Deck Material |
7 Gauge Steel |
| Deck Size |
96 in / 244 cm |
| Discharge Chute |
Rear |
| Drive System |
17.84 cu in Hydro-Gear HGM-H Motors with 18 cc Kanzaki® Pump |
| Drive Tires |
26 in. x 12 in. – 12 in. (66.0 cm x 30.5 cm x 30.5 cm) |
| Engine |
37 hp* Yanmar® Diesel 1642 cc |
| Engine Brand |
Yanmar |
| Engine Displacement (cc) |
1642 cc |
| Engine Horsepower |
37 hp |
| Foot Operated Height of Cut |
Hydraulic with Rocker Switch |
| Forward Ground/Transport Speed |
Up to 12.5 mph / 20.1 kph |
| Forward Mowing Speed |
Up to 12.5 mph / 20.1 kph |
| Front Bumper |
Bull-Nose |
| Fuel Capacity |
12.5 gal. / 47.3 L / 50 Qt. |
| Fuel Type |
Diesel |
| Greasable Bearings |
No |
| Height of Cut |
1.0 – 5.5 in. / 2.5 – 14.0 cm |
| Hour Meter |
Horizon™ Technology |
| Notes |
ROPS Height (Folded) 51 in. (129.5 cm), ROPS Height (Upright) 71.8 in. (182.4 cm) |
| Number of Blades |
4 |
| Product Features |
Anti-Scalp Rollers, Cup Holder, Deck Lift Assist, Diesel, EFI, Electric Start, Foot Operated Height of Cut, Horizon System, Rear Discharge |
| Product Type |
Zero Turn Mowers |
| Roll-Over Protection System (ROPS) |
Standard |
| Seat |
Deluxe Suspension Seat |
| Spindle Bearings |
Maintenance-free |
| Spindle Housing |
9 in / 22.9 cm Diameter Cast Aluminum |
| Start Type |
Electric |
| Steering Controls |
1-5/8″ (4.1 cm) Diameter Grips; Adjustable, Dampened |
| Terrain Type |
Rough Terrain |
| Weight |
2,635 lbs / 1,195 kg |
