Heavy-Duty
12.75″ diameter flail tube for increased rigidity resulting in smoother operation.
Tri-lateral hood design and spiral-mounted knives deliver four times the cutting action, slicing crop residue into smaller pieces for faster decomposition.
Special oil seal protectors prevent vines from damaging the gearbox. A high-capacity gearbox with a large oil volume keeps bearings cool and extends gearbox life.
| Product Tier |
Heavy-Duty
|
|---|---|
| Minimum Tractor PTO HP |
150
|
| Driveline 2 Point and 3 Point |
CAT 6
|
| Adjustable Cutting Height (in) |
14-Feb
|
| Cutting Width (in) |
303
|
| Overall Width (in) |
310
|
| Weight (lbs) |
5,838
|
| Number of L Knives |
288
|
| Lift HP Required |
150
|
| Flail Tube Diameter (in) |
12.75
|
| Flail Tube End Bearing (in) |
2.18
|
| Knife Retention |
Bolt-on (no D-rings)
|
| Knife Pattern |
Spiral
|
| Knife Types |
Double-edged L (6mm), double-edged HD-cotton Duraface® (8mm) L
|
| Wheel Size (in) |
9.5L x 15
|
| Wheel Arm Types |
Rigid Strut
|
| Gearbox Rating (HP) |
300 *Gearbox horsepower ratings listed are based on field testing.
|
| Optional Friction Clutch |
24,000 lbs inch rating
|
| Automatic Clutch |
30,000 lbs inch rating (1.75-inch 20 PTO only)
|
| Gearbox Warranty |
6 years – limited
|
| Optional Hitches |
2-point, 3-point (quick-hitch compatible) pull
|
| Pull-type |
CAT 6 CV
|
| Pull HP Required |
150
|
| Hood Type |
Smooth, trilateral shape
|
| Hood/Deck Thickness (in) |
.18 (optional wearliner available)
|
| End Plate Thickness (in) |
0.25
|
