Specs
| Product Tier |
Standard
|
|---|---|
| PTO Power Requirements (HP) |
15-30
|
| Operating Weight; including chute & hydraulic deflector (lbs) |
465
|
| Working Width (in) |
53 1/2
|
| Working Height (in) |
25 1/4
|
| Overall Width (in) |
54 3/4
|
| Overall Length (in) |
40 1/2
|
| Impeller Diameter (in) |
22
|
| Impeller Width (in) |
6
|
| Impeller (rpm) |
540
|
| Main Auger Diameter (in) |
15
|
| Auger Driven System |
Chain No. 60
|
| Auger (rpm) |
170
|
| Chute Rotation |
Manual or Hydraulic
|
| Replaceable and Reversible |
Yes
|
| Cutting Edge Dimension (in) |
3/8 x 1 1/2
|
| Main Driving System |
Driveline Series 40
|
| Chain Idler |
Yes
|
| Number of Auger Shear Bolt |
1 (on drive shaft)
|
| Number of Impeller Shear Bolt |
1 (on driveline)
|
| Type of Hitch |
3 pts., CAT 1
|
| Parking Stand |
Standard
|
| Gearbox Warranty |
6-years Includes Seals
|
