Specs
| Product Tier |
Standard
|
|---|---|
| Tractor PTO 540 rpm (HP) |
15-35
|
| Hitch |
Limited CAT 1 / CAT 1
|
| Cutting Width (in) |
60
|
| Adjustable Cutting Height (in) |
1.5 – 5
|
| Chain Shielding |
Optional
|
| Overall Width (in) |
61
|
| Operation Weight, w/Chains (lbs) |
481
|
| Deck Thickness (in) |
0.141
|
| Blade Size (in) |
.25 x 2.5 x 21
|
| Blade Tip Speed (fpm) |
17,900
|
| Blade Overlap (in) |
1.25
|
| Blade Spindles/Bearings |
Cast iron housing / lubed-for-life
|
| Belt and Belt Adjustment |
B-section Aramid / Spring-loaded idler
|
| Driveline Category |
CAT 3
|
| Gearbox Rating (HP) |
35
|
| Caster Wheels |
3.5 x 8.0 solid rubber
|
| Sheave Type |
Cast-iron
|
| Side Skirt |
7 ga x 4.8 deep
|
| Rear Chain Shielding Option |
Yes
|
| Anti-scalp Roller Options (front and rear) |
Yes
|
| Blade Options |
Hi-lift/Low-lift
|
| Mower Warranty |
1-year residential or 90-days commercial
|
| Gearbox & Seal Warranty |
6 year
|
| Spindle Warranty |
1 year
|
| Quick-hitch Ready |
Yes
|
| Woods C® |
|
