Specs
| Product Tier |
Professional
|
|---|---|
| Tractor PTO 540 rpm (HP) |
25-50
|
| Hitch |
CAT 1
|
| Cutting Width (in) |
84
|
| Adjustable Cutting Height (in) |
1.5-5
|
| Chain Shielding |
Optional
|
| Overall Width (in) |
85
|
| Operation Weight, w/Chains (lbs) |
817
|
| Deck Thickness (in) |
0.188
|
| Blade Size (in) |
.313 x 2.5 x 29
|
| Blade Tip Speed (fpm) |
18,100
|
| Blade Overlap (in) |
1.5
|
| Blade Spindles/Bearings |
Ductile iron housings / triple ball bearings, greasable
|
| Best and Belt Adjustment |
B-section Aramid / Spring-loaded w/Bearing Pivot
|
| Driveline Category |
CAT 3
|
| Gearbox Rating (HP) |
60
|
| Caster Wheels |
4 x 10 solid rubber
|
| Floating Lower Hitch |
Yes
|
| Spindle Housing |
Ductile iron
|
| Greasable Spindle |
Yes
|
| Spindle Sheave Type |
Cast-iron
|
| Deck Depth (in) |
5.38
|
| Lower Hitch Type |
Clevis
|
| Caster Pivot Bushings |
Yes
|
| Belt Cover |
Yes
|
| Rear Chain Shielding Option |
Yes
|
| Blade Options |
Hi-lift, low-lift, mulch
|
| Quick-hitch Ready |
Yes
|
| Gearbox Warranty |
10 year
|
| Mower Warranty |
1 year
|
| Spindle Warranty |
3 year
|
| Structure Warranty |
2 years
|
