Specs
Operating Weight
- SAE J 1197
- 10,802 lbs
- 4,900 kg
This div for css purpose only
Engine Power
- Net power rating at 2,200 rpm (SAE J 1349)
- 62 hp
- 46.2 kW
This div for css purpose only
Performance
- Bucket Capacity
- 1.05-1.57 yd3
- 0.8-1.2 m3
- Tipping Load, Straight
- 8,311 lbs
- 3,770 kg
- Tipping Load, Articulated
- 7,341 lbs
- 3.330 kg
- Drawbar Pull
- 9,441.98 lbs (L) 9,666.78 lbs (H)
- 4,282.81 kg (L) 4,384.78 kg (H)
Steering
- Total steering angle
- 80 deg.
- 80 deg.
This div for css purpose only
Brakes
- Auxiliary brake
- Service brake hydraulically actuated center-mounted disc brake, acting in all 4 wheels via 4-wheel drive
- Service brake hydraulically actuated center-mounted disc brake, acting in all 4 wheels via 4-wheel drive
This div for css purpose only
Tires
- Standard
- 405/70 R18 Goodyear Powerload
- 405/70 R18 Goodyear Powerload
This div for css purpose only
