$649.99
|
24″, 3/8″ X-Cut, RancherBar FA RTLBX
970 61 39‑54
|
|
|---|---|
|
Engine
|
|
Output shaft power1 |
3.62 hp
|
Cylinder displacement |
60.3 cm³
|
Torque, max. |
3.4 Nm
|
Torque, max. at rpm |
7,000 rpm
|
Chain speed at max power |
65.62 fts
|
Clutch engagement speed (±120) |
3,900 rpm
|
Electrode gap |
0.02 in
|
Idling speed |
2,700 rpm
|
Ignition module air gap |
0.01 in
|
Maximum power speed |
9,000 rpm
|
Oil pump capacity, max |
17 ml/min
|
Oil pump capacity, min |
6 ml/min
|
Oil pump type |
Automatic
|
Spark Plug |
Champion RCJ7Y, NGK BPMR7A
|
|
24″, 3/8″ X-Cut, RancherBar FA RTLBX
970 61 39‑54
|
|
|---|---|
|
Equipment
|
|
Recommended bar length, min |
13 in
|
Pitch |
3/8″
|
Recommended bar length, max |
24 in
|
Chain type |
S83G
|
Bar length |
60 cm
|
Bar length (inch) |
24 in
|
Sprocket type |
Spur 7
|
Gauge |
.058″
|
|
24″, 3/8″ X-Cut, RancherBar FA RTLBX
970 61 39‑54
|
|
|---|---|
|
Dimensions
|
|
Weight (excl. cutting equipment) |
13.2 lbs
|
|
24″, 3/8″ X-Cut, RancherBar FA RTLBX
970 61 39‑54
|
|
|---|---|
|
Sound and noise
|
|
Sound pressure level at operators ear (LpA) |
105 dB(A)
|
Sound power level, guaranteed (LWA) |
115 dB(A)
|
Sound power level, measured |
113 dB(A)
|
|
24″, 3/8″ X-Cut, RancherBar FA RTLBX
970 61 39‑54
|
|
|---|---|
|
Vibration
|
|
Equivalent vibration level (ahv, eq) rear handle |
6.9 m/s²
|
Equivalent vibration level (ahv, eq) front handle |
3.8 m/s²
|
|
24″, 3/8″ X-Cut, RancherBar FA RTLBX
970 61 39‑54
|
|
|---|---|
|
Lubricant
|
|
Oil tank volume |
0.7 US pint
|
Lubricant type (Engine) |
Husqvarna 2 stroke or equiv. at 50:1
|
|
24″, 3/8″ X-Cut, RancherBar FA RTLBX
970 61 39‑54
|
|
|---|---|
|
Emission
|
|
Exhaust emissions (CO₂ EU V)2 |
825 g/kWh
|
