$819.99
|
16″ SN .325″ 1,3 mm SP33G
967 69 09‑36
|
18″ SN .325″ 1,3 mm SP33G
967 69 09‑38
|
|
|---|---|---|
|
Engine
|
||
Output shaft power1 |
4 hp
|
4 hp
|
Cylinder displacement |
50.1 cm³
|
50.1 cm³
|
Torque, max. |
3.15 Nm
|
3.15 Nm
|
Torque, max. at rpm |
7,800 rpm
|
7,800 rpm
|
Chain speed at max power |
64.3 fts
|
64.3 fts
|
Clutch engagement speed (±120) |
3,900 rpm
|
3,900 rpm
|
Electrode gap |
0.02 in
|
0.02 in
|
Idling speed |
2,800 rpm
|
2,800 rpm
|
Ignition module air gap |
0.01 in
|
0.01 in
|
Maximum power speed |
10,200 rpm
|
10,200 rpm
|
Oil pump type |
Adjustable flow, no flow at idle
|
Adjustable flow, no flow at idle
|
Spark Plug |
NGK CMR6H
|
NGK CMR6H
|
|
16″ SN .325″ 1,3 mm SP33G
967 69 09‑36
|
18″ SN .325″ 1,3 mm SP33G
967 69 09‑38
|
|
|---|---|---|
|
Equipment
|
||
Recommended bar length, min |
13 in
|
13 in
|
Pitch |
.325″
|
.325″
|
Recommended bar length, max |
20 in
|
20 in
|
Chain type |
SP33G
|
SP33G
|
Bar length |
40 cm
|
45 cm
|
Bar length (inch) |
16 in
|
18 in
|
Sprocket type |
Rim 7
|
Rim 7
|
Gauge |
.050″
|
.050″
|
|
16″ SN .325″ 1,3 mm SP33G
967 69 09‑36
|
18″ SN .325″ 1,3 mm SP33G
967 69 09‑38
|
|
|---|---|---|
|
Dimensions
|
||
Weight (excl. cutting equipment) |
12.3 lbs
|
12.3 lbs
|
|
16″ SN .325″ 1,3 mm SP33G
967 69 09‑36
|
18″ SN .325″ 1,3 mm SP33G
967 69 09‑38
|
|
|---|---|---|
|
Sound and noise
|
||
Sound pressure level at operators ear (LpA) |
107 dB(A)
|
107 dB(A)
|
Sound power level, guaranteed (LWA) |
117 dB(A)
|
117 dB(A)
|
Sound power level, measured |
115 dB(A)
|
115 dB(A)
|
|
16″ SN .325″ 1,3 mm SP33G
967 69 09‑36
|
18″ SN .325″ 1,3 mm SP33G
967 69 09‑38
|
|
|---|---|---|
|
Vibration
|
||
Equivalent vibration level (ahv, eq) rear handle |
4.6 m/s²
|
4.6 m/s²
|
Equivalent vibration level (ahv, eq) front handle |
4 m/s²
|
4 m/s²
|
|
16″ SN .325″ 1,3 mm SP33G
967 69 09‑36
|
18″ SN .325″ 1,3 mm SP33G
967 69 09‑38
|
|
|---|---|---|
|
Lubricant
|
||
Oil tank volume |
0.68 US pint
|
0.68 US pint
|
Lubricant type (Engine) |
Husqvarna 2 stroke or equiv. at 50:1
|
Husqvarna 2 stroke or equiv. at 50:1
|
|
16″ SN .325″ 1,3 mm SP33G
967 69 09‑36
|
18″ SN .325″ 1,3 mm SP33G
967 69 09‑38
|
|
|---|---|---|
|
Emission
|
||
Exhaust emissions (CO₂ EU V)2 |
813 g/kWh
|
813 g/kWh
|
