$629.99
|
12″ SN 3/8 mini” 1,3 mm S93G
967 63 33‑12
|
12″ SN 3/8″ mini 1,3 mm S93G
970 73 72‑12
|
|
|---|---|---|
|
Engine
|
||
Output shaft power1 |
1.48 hp
|
1.48 hp
|
Cylinder displacement |
27 cm³
|
27 cm³
|
Torque, max. |
1.28 Nm
|
1.28 Nm
|
Torque, max. at rpm |
6,000 rpm
|
6,000 rpm
|
Chain speed at max power |
59.4 fts
|
59.4 fts
|
Clutch engagement speed (±120) |
4,200 rpm
|
4,200 rpm
|
Electrode gap |
0.02 in
|
0.02 in
|
Idling speed |
2,900 rpm
|
2,900 rpm
|
Ignition module air gap |
0.02 in
|
0.02 in
|
Maximum power speed |
13,500 rpm
|
13,500 rpm
|
Oil pump type |
Adjustable flow
|
Adjustable flow
|
Spark Plug |
NGK CMR6A
|
NGK CMR6A
|
|
12″ SN 3/8 mini” 1,3 mm S93G
967 63 33‑12
|
12″ SN 3/8″ mini 1,3 mm S93G
970 73 72‑12
|
|
|---|---|---|
|
Equipment
|
||
Recommended bar length, min |
8 in
|
8 in
|
Pitch |
3/8″ mini
|
3/8″ mini
|
Recommended bar length, max |
12 in
|
12 in
|
Chain type |
S93G
|
S93G
|
Bar length |
30 cm
|
30 cm
|
Bar length (inch) |
12 in
|
12 in
|
Sprocket type |
Spur
|
Spur
|
Gauge |
.050″
|
.050″
|
|
12″ SN 3/8 mini” 1,3 mm S93G
967 63 33‑12
|
12″ SN 3/8″ mini 1,3 mm S93G
970 73 72‑12
|
|
|---|---|---|
|
Dimensions
|
||
Weight (excl. cutting equipment) |
5.95 lbs
|
5.95 lbs
|
|
12″ SN 3/8 mini” 1,3 mm S93G
967 63 33‑12
|
12″ SN 3/8″ mini 1,3 mm S93G
970 73 72‑12
|
|
|---|---|---|
|
Sound and noise
|
||
Sound pressure level at operators ear (LpA) |
98 dB(A)
|
98 dB(A)
|
Sound power level, guaranteed (LWA) |
111 dB(A)
|
111 dB(A)
|
Sound power level, measured |
110 dB(A)
|
110 dB(A)
|
|
12″ SN 3/8 mini” 1,3 mm S93G
967 63 33‑12
|
12″ SN 3/8″ mini 1,3 mm S93G
970 73 72‑12
|
|
|---|---|---|
|
Vibration
|
||
Equivalent vibration level (ahv, eq) rear handle |
5.2 m/s²
|
5.2 m/s²
|
Equivalent vibration level (ahv, eq) front handle |
4.9 m/s²
|
4.9 m/s²
|
|
12″ SN 3/8 mini” 1,3 mm S93G
967 63 33‑12
|
12″ SN 3/8″ mini 1,3 mm S93G
970 73 72‑12
|
|
|---|---|---|
|
Lubricant
|
||
Oil tank volume |
0.36 US pint
|
0.36 US pint
|
Lubricant type (Engine) |
Husqvarna 2 stroke or equiv. at 50:1
|
Husqvarna 2 stroke or equiv. at 50:1
|
|
12″ SN 3/8 mini” 1,3 mm S93G
967 63 33‑12
|
12″ SN 3/8″ mini 1,3 mm S93G
970 73 72‑12
|
|
|---|---|---|
|
Emission
|
||
Exhaust emissions (CO₂ EU V)2 |
–
|
850 g/kWh
|
